6 once all cable information is entered hit calculate.
Cable tray formula.
An example how to calculate voltage drop and size of electrical cable photo credit.
On tue dec 2 2014 at 7 52 pm electrical notes articles wrote.
Cable load working load the cable load or the working load is the total weight of the cables to be placed in the tray.
Calculate size of cable tray for following cable schedule.
Cable tray is sized based on the number and type of cables required for the current and future need.
Calculate cable tray width calculate cable tray area calculate cable tray length calculate cable tray weight calculate remaining width of cable tray calculate remaining area of cable tray free download.
Quick tray wire mesh cable tray fill table at 50.
Cable is directed buried in ground in trench at the depth of 1 meter ground temperature is approximate 35 deg.
The sum of the cross sectional areas of all cables cannot exceed 50 of the trays fill area.
Cable are laying in single layer in cable tray.
The quick tray wire mesh cable tray fill table below shows the number of cables and the load in lbf lineal foot developed by typical 4 pair and 6 pair cable weighing 20 lb kft and 40 lb kft respectively while this table is a useful guide actual loads must be calculated using the cable specified.
Please subscribe techengineer give your wonderful support to us.
Cable tray should be perforated and 20 spare capacity.
Cable trays may be filled 50 when using control or signal wiring.
In this video we are going to discuss about cable tray size and perfect tray selected.
A 50 fill ratio should equal the maximum number of cables pulled in a given cross section.
The cable tray sizing equals the width times the loading depth.
This is the total weight of cables in the tray.
The nema classes are based on cable loads of 50 75 and 100 per lineal foot.
1 2 no s of 3 5cx300 sq mm xlpe cable having 59 7mm outer diameter and 5 9 kg meter weight 2 2 no s of 3 5cx400 sq mm.
7 once the calculate button has been selected the program will take you to the output page where the tray size needed will be displayed as well as the article of the nec that it falls under.
Distance between each cable is 10mm.
