Cable Tool Drilling Method

The percussion method of drilling cable tool churn drills sputter or pounders it s sometimes referred to is one of the oldest cutting actions utilized in the drilling industry.

Cable tool drilling method.

To operate a cable tool rig you must be able to use welder to build bit up and weld steel casing. The debris is then mucked out by a bailer a bucket with a trapdoor bottom that scoops out the overburden. Cable tool drilling also known as percussion drilling or spudding is a widely used well drilling method in michigan. Some rigs are combination rotary cable tool enabling the operator to use the rotary along with the casing driving ability of the cable tool.

Where the percussive method of drilling is employed cable drilling is commonly adopted for holes deeper than 30 m. Water oil or gas. This is a 71 speed star cable tool drilling rig. Cable tool drilling is a method of drilling in which a hole is made by the repeated blows generated by lifting and dropping a heavy chisel bit on rocks or underground formations.

The hammer is then re employed and the process repeats. Cable tool drilling rates are 30 to 80 ft per day depending on formations and size of cable tool rig. Michigan has more cable tool rigs than any other type of drilling machine. Cable tool rigs are a traditional way of drilling water wells.

Rotary rigs can drill 100 to 1000 ft per day depending on size of rig and formation types. Rope drilling or cable drilling. The cable refers to the manila hemp rope used to suspend the wooden rods and the drilling tools in the earliest operations. Cable tool was the first method used to drill a bore hole and is still in use particularly for shallow oil or gas wells in the appalachian basin.

I have a 6 and 8 pit 6 and 8 bailers for the rig. A cable raises turns and drops a hammer pulverizing the soil in the hole. The majority of large diameter water supply wells especially deep wells completed in bedrock aquifers were completed using this drilling method. In this system the rigid rods are replaced by a steel wire rope to which the drilling tool is attached.

The heavy usually blunt chisel bit is the tool and the cable could be made of something as simple as a manila rope or multiple steel strands wireline. Developed in china over 4 000 years ago the cable tool is tried and true responsible for millions of successful wells around the world.
